Angelbird SSD AV PRO XT 6,4 cm (2,5″) 1 TB SATA 6 Gb/s
Professional SSD designed for your demanding Audio and Video tasks.
As an audio/video professional, you know tat when the action starts, there’s no time for second-guessing – you and your gear must be ready to go, and you either act with confidence or risk losing the shot. features robust 7mm casing and high compatibility with your cameras, recorders, and players.
Specifications and Features
• up to 550 MB/s | up to 86.000 IOPS
• Shock & temperature proof
• 500 GB / 1 TB / 2 TB / 4TB
• X-ray & magnetic proof
• Stable Stream TM
• ESD & overload protection
• Adaptive thermal protection
• Sticker-Free TM – hassle free and enviromental friendly
• Host power loss protection
• Rock-solid build
• Video / Photo / Audio
• Mac / Windows / Linux
SPECIFICATIONS
GENERAL SPECIFICATIONS
• Capacity: 500 GB, 1 TB, 2 TB, 4TB
• Dimensions: 100,2 x 69,9 x 7,0mm | 3,94 x 2,75 x 0,28in
• Form Factor: 2.5in slim |7mm
• Weight: ca. 77g | ca. 2,7oz
TECHNICAL SPECIFICATIONS
• Interface: SATA 6Gb/s, 3Gb/s and 1.5Gb/s supported | SATA 3.0 compliant
• Over provisioning: ca. 9%
• Flash: Grade A Synchronous MLC
• Features: Temperature sensor, overload protection, built-in cache, SMART, NCQ, adaptive thermal protection
PERFORMANCE SPECIFICATIONS
• Sustained Read Speed1: up to 550 MB/s
• Sustained Write Speed1: up to 510 MB/s
• IOPS2: up to 86,000
• Access Time (R/W): ca. 65 µs / 40 µs
RELIABILITY SPECIFICATIONS
• MTBF: > 1,500,00 hours
• Data Reliability: Built-in EDC / ECC function
• Data Retention: 10 years at 25°C
• Endurance: 500 GB: up to 120 TBW | 1 TB: up to 240 TBW | 2 TB: up to 500 TBW
• Certifications: RoHS, FCC and CE compliant, REACH
ELECTRICAL SPECIFICATIONS
• DC input voltage: 5V ± 10%
• Power usage (idle/max):
– 500 GB: 1,35 W / 4,7 W
– 1 TB: 1,35 W / 5,4 W
– 2 TB: 1,80 W / 5,4 W
ENVIRONMENTAL SPECIFICATIONS
• Shock resistance (operating): 1000 G/0,5 ms
• Vibration resistance (operating): 2,17 Grms
• Operating Temperature: 0°C ~ +70°C
• Storage Temperature: -40°C ~ +85°C
• Operating Humidity: 5% to 95% con-condensing
CERTIFICATIONS
• Atomos certified product
• Blackmagic Design certified product
WARRANTY3
3-year limited warranty
PACKAGE CONTENT
• SSD AVPRO XT
• Activation code for the full limited warranty and additional free software licenses and content
1 Measured with ATTO Benchmark Tool 3.05
2 Disk aligned / 4KB random write / QD=32
3 To receive the full limited warranty, the product needs to be registered on the Angelbird Personal Service Portal within 30 days after purchase. If not registered within this period, the market-specific legal guarantee period comes into force.
As an audio/video professional, you know tat when the action starts, there’s no time for second-guessing – you and your gear must be ready to go, and you either act with confidence or risk losing the shot. features robust 7mm casing and high compatibility with your cameras, recorders, and players.
Specifications and Features
• up to 550 MB/s | up to 86.000 IOPS
• Shock & temperature proof
• 500 GB / 1 TB / 2 TB / 4TB
• X-ray & magnetic proof
• Stable Stream TM
• ESD & overload protection
• Adaptive thermal protection
• Sticker-Free TM – hassle free and enviromental friendly
• Host power loss protection
• Rock-solid build
• Video / Photo / Audio
• Mac / Windows / Linux
SPECIFICATIONS
GENERAL SPECIFICATIONS
• Capacity: 500 GB, 1 TB, 2 TB, 4TB
• Dimensions: 100,2 x 69,9 x 7,0mm | 3,94 x 2,75 x 0,28in
• Form Factor: 2.5in slim |7mm
• Weight: ca. 77g | ca. 2,7oz
TECHNICAL SPECIFICATIONS
• Interface: SATA 6Gb/s, 3Gb/s and 1.5Gb/s supported | SATA 3.0 compliant
• Over provisioning: ca. 9%
• Flash: Grade A Synchronous MLC
• Features: Temperature sensor, overload protection, built-in cache, SMART, NCQ, adaptive thermal protection
PERFORMANCE SPECIFICATIONS
• Sustained Read Speed1: up to 550 MB/s
• Sustained Write Speed1: up to 510 MB/s
• IOPS2: up to 86,000
• Access Time (R/W): ca. 65 µs / 40 µs
RELIABILITY SPECIFICATIONS
• MTBF: > 1,500,00 hours
• Data Reliability: Built-in EDC / ECC function
• Data Retention: 10 years at 25°C
• Endurance: 500 GB: up to 120 TBW | 1 TB: up to 240 TBW | 2 TB: up to 500 TBW
• Certifications: RoHS, FCC and CE compliant, REACH
ELECTRICAL SPECIFICATIONS
• DC input voltage: 5V ± 10%
• Power usage (idle/max):
– 500 GB: 1,35 W / 4,7 W
– 1 TB: 1,35 W / 5,4 W
– 2 TB: 1,80 W / 5,4 W
ENVIRONMENTAL SPECIFICATIONS
• Shock resistance (operating): 1000 G/0,5 ms
• Vibration resistance (operating): 2,17 Grms
• Operating Temperature: 0°C ~ +70°C
• Storage Temperature: -40°C ~ +85°C
• Operating Humidity: 5% to 95% con-condensing
CERTIFICATIONS
• Atomos certified product
• Blackmagic Design certified product
WARRANTY3
3-year limited warranty
PACKAGE CONTENT
• SSD AVPRO XT
• Activation code for the full limited warranty and additional free software licenses and content
1 Measured with ATTO Benchmark Tool 3.05
2 Disk aligned / 4KB random write / QD=32
3 To receive the full limited warranty, the product needs to be registered on the Angelbird Personal Service Portal within 30 days after purchase. If not registered within this period, the market-specific legal guarantee period comes into force.
